14” x 40” Studer S40 CNC Universal Cylindrical Grinder

Brand
STUDER

Model
S40

Stock #
G1459

Condition
Used

Year
1994

Location
Lake Bluff, Illinois
United States

Specifications

Max. Swing 13.8 inches
Center Distance 39.4 inches
Max. Weight between Centers 290 pounds
Max. Longitudinal Travel (Z-Axis) 41.4 inches
Longitudinal Feed Rate 0.000004 – 394 IPM
Longitudinal Resolution 0.000004”
Max. Table Swivel 8.5°
Max. Wheelhead Slide Travel 10.8 inches
Wheelhead Slide Feed Rate 0.000004 – 394 IPM
Wheelhead Resolution 0.000004”
Right Spindle Wheel Size (Dia x W x Bore) 20" x 3.15" x 5"
Wheelhead Drive 10 HP
Peripheral Speed 6890 SFPM
Swivel Range of Wheelhead -15° to 225°
Workhead Speed Range 30 - 750 RPM
Wheelhead Taper No.3 MT
Tailstock Quill Travel 1.37 inches
Main Spindle Motor 10 HP
Approximate Dimensions (LR x FB x H) 160" x 86" x 84"
Approximate Weight 11500 pounds

Equipped With

Fanuc 16-GC CNC Control. Programmable Positioning of Wheelhead at every 5 degrees. Dittel HBA4000 Wheel Balancer. Manual Pulse Generator. Pneumatic Cylinder on Headstock. Combination Lever/Pneumatic Tailstock. Foot Switch.

This machine is being offered Cleaned, Cycled, and with a 30-Day Return Privilege Guarantee.
