Lapping Plate Size | 28 inches |
Plate Rotation Speed (Variable) | 0 - 100 RPM |
Number of Ring Stations | 3 Pressure Plates |
Conditioning Ring Size | 13.875" OD x 12" ID |
Main Motor | 3 HP |
Pneumatic Down-force Range | 0 - 500 lbs |
Worktable Diameter | 48 inches |
Water Flow Rate | 1 GPM |
Approximate Dimensions | 66"L x 48"W x 77"H |
Approximate Weight | 3500 pounds |
(3) Independently Controlled Adjustable Down Pressure Pneumatic Hold Downs. Pneumatic Counter Balance. Abrasive Slurry Pump. Hyprez Autostirrer Electronic Dispenser of lubricator/slurry spray. (3) Lock Down roller Yoke Assembly. (3) Conditioning Retaining Rings. Parts Handling Table.
Cleaned, Cycled, Guaranteed.
