4' x 14" YMZ/Yamazen Model RH-1300 Radial Drill

Brand
YMZ

Model
RH-1300

Stock #
rd705

Condition
Used

Year

Location
Lake Bluff, Illinois
United States

Specifications

Drilling Capacity, Cast Iron 2.75 inches
Drilling Capacity, Solid Steel 2.375 inches
Maximum Distance from Column Surface to Spindle Center 51.5625 inches
Minimum Distance from Column Surface to Spindle Center 9.0625 inches
Horizontal Travel of Spindle Head 42.5156 inches
Maximum Distance from Base to Spindle 53.125 inches
Minimum Distance from Base to Spindle 13.75 inches
Vertical Travel of Arm 26.75 inches
Traverse of Spindle 14.1719 inches
Morse Taper in Spindle No.5 MT
Range of Spindle Speeds (12) 40 - 2010 RPM
Spindle Feeds 0.03 - 0.04 in/rev
Spindle Drive 7.5 HP
Electrics 3/60/460v
Approximate Weight 8500 pounds
F.O.B. Our Plant

Equipped With

Controls For Column Clamping. Head Clamping. Arm Raising And Lowering. 20" x 23.5" x 16"H Box Table. Coolant. Worklight.

This machine is being offered cleaned, and cycled.  It is being offered with a 30-Day Return Privilege and may be inspected under power here in our plant.
