Daewoo Ace H 100 Horizontal Machining Center









Daewoo Ace H 100 Horizontal Machining Center

Brand
DAEWOO

Model
Ace H 100

Type
Machining Centers, Horizontal

Stock #
HMC100x

Condition
Used

Year
2007

Location
Platteville, Wisconsin
United States

Request a Quote

Specifications

X-axis Travel	78.7”
Y-axis Travel	49.7”
Z-axis Travel	49.7”
Spindle Taper	CAT 50
Spindle Drive Motor	30 hp
Spindle Speed	4500 rpm
Tool Capacity (ATC)	90
Number of Pallets	2
Pallet Size	39.4” x 39.4”
Pallet Size (W)	39.4”
Pallet Size (L)	39.4”
4 Axis Pallet Table Indexing	1 Degree Index
Dimensions	255” x 276” x 141”
Weight	60,000

Equipped With

EQUIPPED WITH:
Fanuc 18MB CNC Controls.

Thru Spindle Coolant.
Cool jet High Pressure Coolant with Cartridge Filters.

1 Degree Indexing.

Chip Conveyor.

(2) T-Slotted Pallets.

90 Position ATC.

Oil Chiller.

Operators Platforms.
